Asus Workstation Pro E500 G7

(0)

SKU : PRO E500 G7

Workstation esensial dengan prosesor Intel® Xeon® W-1300, memori 128GB ECC , LAN 2.5GbE ganda, M.2 ganda, dukungan hingga tiga layar, satu kartu grafis dual-slot, USB 3.2 Gen2x2, dan ASUS Control Center Prosesor Intel Xeon W-1300 dan memori DDR4-3200 ECC untuk kinerja dan stabilitas profesional Siap untuk rendering 2D/3D dengan dukungan untuk satu NVIDIA® Quadro RTX™ Port ethernet 2.5GbE onboard ganda untuk komputasi dengan kepadatan tinggi, bandwidth tinggi, dan latensi rendah yang lebih cepat Mendukung modul Intel WiFi 6 Dual M.2 hingga 32Gbps untuk performa dan redundansi data yang lebih baik Konektivitas ultra cepat dengan USB Type-C 3.2 Gen 2.2, USB Type A dan C 3.2 Gen 2, dan USB 3.2 Gen 1 Dukungan hingga tiga layar independen secara bersamaan melalui HDMI, DisplayPort, DVI-D, dan VGA Independent software vendor (ISV) untuk keandalan dan kompatibilitas yang teruji pada aplikasi penting.

Rp49.500.000

Quantity

Categories : Server

Brands :ASUS

Deskripsi Produk

Operating System

Windows 10 Pro - ASUS recommends Windows 11 Pro for business.
Windows 10 Home - ASUS recommends Windows 11 Pro for business.
Processor / System Bus

1 x Socket LGA1200
Intel® Xeon® W-1350 Processors
Core Logic

Intel® W580 Chipset
Memory

Total Slots :
4 (2-channel)
Capacity :
Maximum up to 128GB UDIMM
Memory Type :
Dual Channel DDR4 3200/2933 non ECC and with ECC
Memory Size : 16GB
* Refer to support page for more information
* Actual memory frequency differs from Intel CPU types and memory module. Please check Intel official site for more detail about the memory types supported by each CPU.
Expansion Slots

Total: 5
Location-1: PCIe x16 slots (Gen4 x16/x8 link, FH, FL)
Location-2: PCIe x1 slots (Gen3 x1 link, FH, FL)
Location-3: PCIe x16 slots (Gen4 x0/x8 link, FH, FL)
Location-5: PCIe x16 slots (Gen4 x4 link, FH, FL)*1
Location-6: PCIe x16 slots (Gen3 x4 link, FH, FL)
* the bandwidth of PCIe link is shared with M.2_2

Storage M.2 512GB SSD NVME

Storage Controller :
Intel® W580 Chipset
8 x SATA3 6Gb/s ports
Intel® Rapid Storage Technology(RST) (For Windows Only)
(Support Software RAID 0, 1, 5, 10 )
1 x M.2_1 socket3, up to 2280 type (SATA mode & PCIe Gen3 x4 link) *2
1 x M.2_2 socket3, up to 22110 type (PCIe Gen4 x4 link) *3
Drive Bays

2 x internal 5.25 Drive bays
3 x internal 3.5 Drive bays
1 x Internal 2.5" Drive bay
Auxiliary Storage FDD/CD/DVD

2 x 5.25" media bays
(Options: No ODD/DVD-RW)
Networking

2 x Intel® I225-LM 2.5GbE LAN
Multi-GPU Support

Please find the latest GPU support from https://servers.asus.com/support/gpu
Front I/O Ports

1 x USB 3.2 Gen2x2 port
2 x USB 3.2 Gen1 ports
1 x USB 2.0 port
1 x Headphone port
1 x Microphone port
Rear I/O Ports

2 x USB 3.2 Gen2 ports (1 port at Type A, 1 port at Type C)
4 x USB 3.2 Gen1 ports
1 x HDMI
1 x DisplayPort
1 x DVI-D
1 x VGA
2 x LAN ports (RJ45)
1 x 7.1-channel Audio I/O ports (5+1 Audio jacks)
OS Support

Please find the latest OS support from https://servers.asus.com/support/os
Management Solution

ASUS Control Center Enterprise (Optional)
Regulatory Compliance

BSMI, CE, FCC(Class B), Energy Star
Dimensions

423mm x 190mm x 435mm
16.7" x 7.48" x 17.1"
Weight

Net Weight : 9.9 KG
Gross Weight : 12.1 KG
Power Supply

300W Bronze ATX Power Supply (100-127/220-240Vac, 6-3A, 50-60Hz, Class I)
550W Gold ATX Power Supply (100-240Vac, 9-4.5A, 50-60Hz,)
750W Gold ATX Power Supply (100-240Vac, 9-4.5A, 50/60Hz)
Environment

Operation temperature: 10 ~ 35
Non operation temperature: -40 ~ 70
Non operation humidity: 20% ~ 90% ( Non condensing)
Optional Items

Anti-Virus CD pack
OS
DVD-ROM
Keyboard and mouse
Print port cable
Note

*1 PCIe Bandwidth is shared between M.2 socket and PCIex1.
SATA Bandwidth is shared between M.2 socket and SATA port.
*Intel® vPro support
*2 SATA Bandwidth is shared with 1 SATA port
*3 PCIe Bandwidth is shared with PCIe x16_3
